LFH600602C
600V CLASS H BLOCK 60A 2 POLE NON-ID | Series: LFH
The new Littelfuse Class H blocks offer many advantages over previous generations that are noted in the features and benefits section. Class H and Class R fuse blocks are dimensionally the same, but Class R blocks incorporate a rejection feature, which only allows Class R fuses to be inserted.
Note: For reinforcing clips on Class H blocks rated 30-60 amp, add "R" suffix to connector type
| Property | Value |
|---|---|
Fuse Type | Class H/K |
Indicating | No |
Ampere Rating | 60 |
Fuse Category | General Purpose |
Fusible | Yes |
Holder Family | Fuse Block |
Current Rating Max (A) | 60 |
Max VAC (V) | 600 |
Max VDC (V) | 600 |
Mounting Method | Bolt-In |
UL Class | H |
Maximum AC Voltage | 600 |
Maximum DC Voltage (V) | 600 |
Current Rating (Continuous) in Amps | 60 |
- Indication offered on most 250V and 600V versions
- DIN Rail releasable for all non-knife blade style fuses
- Only one hand is required to release from DIN Rail (lock open lock closed)
- Universal mounting holes make for easy replacement
- Clip designs maximize electrical contact and minimize heat rise
- Reinforcing clips are standard on all Class H fuse blocks rated 100 A and higher.
