LPSM0003ZQCIDE
3 POLE LPSM HOLER W/ QC TERMINALS | Series: LPSM QC
The POWR-SAFE, quick-connect LPSM QC Series dead front fuse holders feature touch-safe protection for personnel when installing and removing fuses. The compact fuse holder mounts quickly onto a 35 mm DIN-rail, decreasing panel
layout and assembly time. This product has two quick-connect terminals on both the top and bottom of the holder, offering an additional connection option. These fuse holders are available in 1-, 2-, 3- and 4-pole configurations and are
intended for use with midget-style (10x38 mm) and Class CC fuses.
| Property | Value |
|---|---|
Fuse Type | Midget |
Indicating | Yes |
Terminal Type | Pressure Plate |
Ampere Rating | 30 |
Body Material | Thermoplastic |
Holder Family | Fuse Block |
Voltage Rating (Ac) | 600 |
Voltage Rating (Dc) | 600 |
- Dual ¼” quick-connect terminals on top and bottom
- Meets dead front requirements
- 35 mm DIN-rail mountable
- Local LED indication
- Simplifies installation
- Offering maximum safety for personnel
- Provides easy installation in various settings
- Quickly shows blown fuse to save time
LPSM0003ZQCIDE Applications
- For use with Class CC and midget-style (10 x 38 mm) fuses
LPSM0003ZQCIDE Resources
