0MBB350
350A, 125 VDC MIDI STYLE BATTERY FUSE | Series: MBBThe Littelfuse MBB fuse series is rated for applications up to 125 V dc. These bolt-down fuses are specially
engineered to provide protection in high power battery charging systems and data servers. Its compact size saves space without sacrificing performance, with a 3kA breaking capacity at rated voltage.
| Property | Value |
|---|---|
Maximum DC Voltage (V) | 125 |
Ampere Rating (Amper) | 350 |
Interrupting Rating
| 3000A |
Operating Characteristic | aR (Partial-range, high-speed) |
Time Constant | 1.2 ms |
Standards | UL 248-13 |
Body Material | Ceramic |
Operating Temperature | -40° to 105°C |
Mounting Method | Bolt Mount |
Nominal Melting I2T (A2sec) | 99000 |
Amp Code (Part Number) | 350 |
Amp Fract | 350 |
Current Rating (Continuous) in Amps | 350 |
Family style | Battery Backup Fuse |
Indicating | No |
Interrupting Rating 1 | 3000A |
Interrupt Voltage Type ACDC - 1 | DC |
Interrupt Voltage | 125V |
Nominal Power Dissipation (W) | 32.5 |
Resistance (Ω) | 0.00013 |
Opening | Very Fast-Acting (FF) |
Size | 500 |
Voltage Rating (Dc) | 125 |
Watts Loss 100 % | 32.5 |
0MBB350 Resources
Link has been copied to clipboardShowing 1 to 1 of 1 Total Results
Share
| Part Number | Part Description | RoHS | Pb-Free | RoHS (2015/863/EU) Certificate | REACH (SVHCs) Declaration | REACH (SVHCs) | Halogen Free | IPC-Material Declaration | |
|---|---|---|---|---|---|---|---|---|---|
| 0MBB350.U | 350A, 125 VDC MIDI STYLE BATTERY FUSE |  CoC_RoHS10_0MBB350.U | REACH_SVHC Declaration_0MBB350.U | Does Not Contain | View More |
