SRP1-CCDD2-050EC-N
SSR HP CL, 1x50A/1200VDC, DC in, IP20 | Series: SRP1-CC...DH
The SRP1-CC...DH series is a family of high-voltage DC solid-state relays designed for switching up to 1700 VDC Peak and 70 A. With models based on IGBT or MOSFET technology, these relays are built for high-performance DC control in energy, transportation, and industrial systems.
- Handles up to 1700 VDC for high-power DC switching applications
- IGBT and MOSFET variants to suit different performance and load profiles
- Built-in diode ensures safe operation with inductive loads by managing energy during turn-off
| Property | Value |
|---|---|
Output Max Current | 50 |
Output Nominal Voltage | 650 V DC |
Output Switching Style | DC |
Input Voltage Range (V) | 5-32 V DC |
Compliance | cЯUus, CE |
Output Overvoltage Protection | - |
- High Voltage Capability (up to 1700 VDC peak)
- Output Technology: IGBT or MOSFET
- Wide Control Voltage Input (5–32 VDC)
- Suitable for demanding applications in renewable energy, rail systems, and DC infrastructure.
- IGBT models deliver efficient high-voltage switching; MOSFET model offers fast switching and better transient handling.
- Simplifies integration with most control systems, including PLCs and industrial controllers.
SRP1-CCDD2-050EC-N Applications
- Battery disconnect and DC switching in solar, marine, and backup power systems
- High-voltage heating in rail and transportation HVAC systems and industrial environments
- DC motors, braking systems, and inductive loads in industrial automation
- Power conversion equipment: UPS, solar inverters, active rectifiers
- Energy storage and smart grid DC systems
SRP1-CCDD2-050EC-N Resources
