KSR2D3MG
KSR2D3MG LFG | Series: KSR D
The KSR D series switches are long-lasting and compact, featuring gold contacts, G terminations and a soft actuator. Engineered for use in the automotive, industrial electronics, and medical equipment industries, KSR D switches give designers a high-quality switch that fits in their most innovative products.
| Property | Value |
|---|---|
Circuitry | SPST NO |
Activation Type | Momentary action |
Rating - Minimum Current | 1 mA |
Contact Plating | Gold |
Electrical Travel | Min 0.15 mm / Nominal 0.3 mm / Max 0.45 mm |
Mechanical Life Cycles | 100000 |
Electrical Rating - Activated - Voltage DC | Min 0.02 Volt / Max 32 Volt |
Ingress Protection | IP 40 |
Terminals Type | Surface mount |
Terminals Plating | Lead free gold |
Terminals Complementary Information | G |
Operating Force | Min 1 N / Nominal 1.5 N / Max 2 N |
Height | 2.5 |
Activation Orientation | Top actuated |
Washing Process - Compatibility | Not Compatible |
Illumination | Not applicable |
- Gold contacts
- G terminations
- Soft actuator
- RoHS compliant and compatible
KSR2D3MG Applications
- Automotive
- Industrial electronics
- Medical equipment
- Detector switch applications
KSR2D3MG Resources
