SRP1-CRAZH-025TC-N
SSR Panel, 1x25A/600VAC ZC, AC in, IP20 | Series: SRP1-CR
| Property | Value |
|---|---|
Output Max Current | 25 A |
Output Nominal Voltage | 48-600 V AC |
Output Switching Style | Zero Cross |
Output Overvoltage Protection | TVS |
Input Voltage Range (V) | 90-280 V AC |
Compliance | cЯUus, CE |
SRP1-CRAZH-025TC-N Resources
Link has been copied to clipboardShowing 1 to 1 of 1 Total Results
Share
| Part Number | Part Description | RoHS | Pb-Free | RoHS (2015/863/EU) Certificate | REACH (SVHC's) Declaration | REACH (SVHC's) | Halogen Free | IPC-Material Declaration | |
|---|---|---|---|---|---|---|---|---|---|
| SRP1-CRAZH-025TC-N | SSR Panel, 1x25A/600VAC ZC, AC in, IP20 | View More |
If the product environmental information that you are looking for does not appear in this tab, please complete the Product Environmental Information Request Form.
